Description
?Single range：
Voltage：0～2250V
Current：0～±4500A
Power：0～±180kW
? The master and slave parallel machines can extend the power up to 1.8MW；
? Voltage accuracy：0.05%+0.05%F.S.；Current accuracy：0.1%+0.1%F.S.；
? PF: 0.99，Overall efficiency higher than 93%； regenerative load function, high regenerative efficiency 95%；
? Two-way energy transfer, seamless switching across quadrants；
? Automatic line loss compensation；
? With constant pressure, constant current, constant power, constant resistance function；
? CV/CC Priority mode；
? Voltage/current slope can be set；
? With voltage output slow rise, slow fall function；
? It has the function of charge and discharge；
? With the function of sequence and waveform, it can realize the complex voltage and current waveform, such as automobile electronic test voltage waveform, user-defined；
? Battery simulator function (optional)；
? Equipped with photovoltaic cell array simulation function (optional)；
? Over volt
Voltage：0～2250V
Current：0～±4500A
Power：0～±180kW
? The master and slave parallel machines can extend the power up to 1.8MW；
? Voltage accuracy：0.05%+0.05%F.S.；Current accuracy：0.1%+0.1%F.S.；
? PF: 0.99，Overall efficiency higher than 93%； regenerative load function, high regenerative efficiency 95%；
? Two-way energy transfer, seamless switching across quadrants；
? Automatic line loss compensation；
? With constant pressure, constant current, constant power, constant resistance function；
? CV/CC Priority mode；
? Voltage/current slope can be set；
? With voltage output slow rise, slow fall function；
? It has the function of charge and discharge；
? With the function of sequence and waveform, it can realize the complex voltage and current waveform, such as automobile electronic test voltage waveform, user-defined；
? Battery simulator function (optional)；
? Equipped with photovoltaic cell array simulation function (optional)；
? Over volt
